TLP521-4(GB)
Optocoupler, Transistor Output, 4 Channel, DIP, 16 Pins, 25 mA, 2.5 kV, 100 {7e82c6d62784066d1b113f595afb6e15f0ca3fec289cddd29e600df910d44428}
Specification
Show similar products (5 097)
Manufacturer
TOSHIBA
Type of optocoupler
optocoupler
Mounting
THT
Number of channels
4
Kind of output
transistor
Insulation voltage
2.5kV
CTR@If
100-600{7e82c6d62784066d1b113f595afb6e15f0ca3fec289cddd29e600df910d44428}@5mA
Collector-emitter voltage
55V
Case
DIP16
Turn-on time
3µs
Turn-off time
3µs
Slew rate
35kV/μs
Show similar products (5 097)
Gross weight
1.812 g
See other products in this category: Optocouplers – analog output TOSHIBA
