RV2-8 Insulated O Ring Terminals PRICE IN PAKISTAN

What Is the RV2‑8? (Ring Terminal Description)

The RV2‑8 is a vinyl‑insulated ring crimp terminal engineered to connect stranded wires securely to a stud or bolt, especially in environments prone to vibration.

Key Features:

• Wire Range: Suitable for 1.5–2.5 mm² (AWStud Size: Fits a 5/16″ (approx. 8.4 mm) stud or bolt

• Materials:

  • Contact: Tin‑plated copper, ensuring conductivity and corrosion resistance.

  • Insulation: Vinyl (PVC), color-coded typically blue for this size

• Dimensions (typical):

  • Barrel length (L): ~26.8 mm (1.10 in)

  • Barrel width (W): ~12 mm (0.47 in)

  • Flat flange (F): ~11 mm (0.43 in)

  • Hole diameter (stud opening): ~8.4 mm (0.33 in) .

• Performance Ratings:

  • Voltage: Up to 600 V

  • Temperature: Up to 105 °C (~221 °F)

  • Current: Typically rated ~20A

• Construction: Butted seam crimp barrel provides a tight, reliable connection

• Feature	Specification
  Wire Size	1.5–2.5 mm² (16–14 AWG)
  Stud Size	5/16″ (≈ 8.4 mm)
  Current Rating	~20A
  Voltage Rating	Up to 600 V
  Temp. Rating	Up to 105 °C
  Materials	Tin‑plated copper & vinyl (PVC) insulation
  Dimensions	L ≈26.8 mm, W ≈12 mm, F ≈11 mm, hole ≈8.4 mm
  Certifications	UL, CE, RoHS, DIN
  Construction	Butted seam crimp barrel

  ---
