Esp32-s3 Devkitc-1 N16r8 Development Board – 16mb Flash, 8mb Psram, Wi-fi & Bluetooth 5.0 Le With External Antenna Connector

SP32 S3 44Pin Price in pakistan | WROOM S3-Devkit N16R8

The ESP32 S3 N16R8 is a specific variant of the ESP32 S3 44Pin series of Wi-Fi & Bluetooth microcontrollers from Espressi f Systems. Here’s a breakdown of its key specifications based on the naming convention  electronicstore.pk give Best ESP32 S3 44Pin

Decoding the Model Name:

• ESP32 S3 → The main series (dual-core Xtensa LX7 MCU, Wi-Fi 4 & Bluetooth 5).
• N16 → 16MB Flash memory (external, typically SPI NOR flash).
• R8 → 8MB PSRAM (external pseudo-static RAM, used for data storage).

Key Features of ESP32-S3 N16R8:

1. CPU: Dual-core Xtensa LX7 (up to 240 MHz).
2. Wireless Connectivity:
   • Wi-Fi 4 (802.11 b/g/n) with 2.4 GHz support.
   • Bluetooth 5 (LE + Mesh).
3. Memory:
   • 16MB Flash (for program storage).
   • 8MB PSRAM (for dynamic data, useful for graphics, audio, etc.).
4. GPIO & Peripherals:
   • Up to 45 programmable GPIOs.
   • USB OTG, SPI, I2C, UART, PWM, ADC, DAC, etc.
5. AI & Vector Instructions:
   • Supports AI acceleration with vector instructions (useful for ML tasks).
6. Low Power Modes:
   • Deep-sleep mode with ultra-low power consumption.
