Ca1235 Adjustable Step Down Power Module Price in Pakistan

LM2596 DC-DC Buck Converter Step Down Power Supply Module with Digital Voltage Display Features Input voltage range:4 40VDC Output voltage range:1.25-37VDC adjustable Output current:2A voltmeter range: 0 to 40V, error 0.1V Input reverse polarity protection Built in output short protection function Built in thermal shutdown function L x W x H =6.1*3.4*12 cm Weight: 22g LED digital voltmeter tube, the accuracy is adjustable function, can be aimed at your multimeter adjustable accurate. Press the right key to let the display show the input or output voltage. when the right OUT led light, it shows output, the left IN led show input.

Input voltage range：4～38VDC(Note: input voltage not exceeding 38V). Output voltage range：1.25-36VDC adjustable. Output current: 0-5A. High efficiency up to 96{7e82c6d62784066d1b113f595afb6e15f0ca3fec289cddd29e600df910d44428}. Output power: 75W. Built-in thermal shutdown function Built-in current limit function In-Built output short protection function Input reverse polarity protection: None (if required, the high current diode in series with the input). Power Indicator: Yes Short circuit protection: Yes (limit current 8A) Overtemperature protection: (automatically shut off the output after overtemperature) Input reverse polarity protection: No, (if necessary, please enter the string into the high current diode) Installation: two 3mm screws Dimensions(LxWxH): 54 x 23 x 15 mm.

The XL7015 DC-DC step-down module is a high efficiency, high voltage step-down DC-DC converter that provides high 0.8A output current capability, low ripple, excellent linearity, and load regulation, and high input voltage. 80V, far more than 2596 and other modules. The chip has multiple protection mechanisms built in. Can be applied to electric vehicle controllers, etc. Features: 5 v to 80 v input voltage range wide. The output voltage from 5 v to 20 v adjustable. The minimum pressure drops 1 v. 0.8 The biggest switch current. Recommend the output power is less than 7 w. Shut off built-in overheating protection, output short circuit protection, over current protection. Good linear with load regulation. The board size: 16 mm * 44 mm. Wiring Instructions: VIN: input voltage (5 v - 80 - v). The GND: input voltage side. The VOUT: output voltage (5 v - 20 v). The GND: output voltage to end. Package Includes: 1XXL7015 DC-DC Buck Converter Step Down Module 5V-80V Wide Voltage Input 7005A Super Than LM2596
