74HC08 Quad 2-input AND gate
Features & Specifications
Four Independent AND Gates
Standard Pin Configuration
Fast Switching Times
Operating Temperature up to 70oC
High-Speed CMOS Type
Type: DIP
Voltage Rating: 2.0 to 6.0V
Temperature Rating: 0 to 70Deg C
Number of: 14 Pins
Mounting: DIP
General Description
The MM74HC08 AND gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. The HC08 has buffered outputs, providing high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground.
