TNC Male to TNC Female Adapter Price in Pakistan

Product Type:SMA Female Jack PCB Mount Connector, End Launch PCB Mount .062" (1.57mm) |Package Contents: SMA female PCB connecctors Impedance:50, Body Material: Brass, Attachment Method:Solder, Frequency Range:3GHz The interface dimensions and technical characteristics are in accord with the specifications of MIL-C-39012.IEC 169-15 and CECC 22110. Applications: Base stations Antennas Telecommunications Instrumentation PC/LAN Never worry about any security problems. We are confident in the quality of our connectors and willing to provide 1 MONTHS Replacement Warranty and 100{7e82c6d62784066d1b113f595afb6e15f0ca3fec289cddd29e600df910d44428} Satisfaction Guarantee. If you unfortunately get a defective one, please contact our customer support.

SMA Male Crimp Connector Key Features SMA plug Gold plated pin, body & ferrule (not pictured) Suits 2.5mm diameter cables such as RG174, RG316, and LMR100 Usage A crimp connector is used to terminate the end of a coaxial cable to allow connection to an RF device or antenna Each series of connector differs by method of connection, size, and electrical properties, allowing a technician to select a connector to best match the intended purpose Most crimp connectors consist of three components - the connector body, pin/socket, and crimping ferrule Terminating a coaxial cable with a crimp connector requires three tools - a wire stripper/cutter, soldering iron, and hex crimp You can find instructional videos on crimping most connectors on YouTube. Crimp Hex Die Sizing RG316/RG174 - 0.128" RG58/LMR195 - 0.213" LMR400/RG8 - 0.429"
