PIC16F57-I/P, 8bit PIC Microcontroller, PIC16F, 20MHz, 2048 x 12 words Flash, 28-Pin PDIP

The Programmer Features By special USB chip CH341A production. USB1.1 communication. Burning speed than ordinary ATMEGA8 25 Series of programming 2-3 times faster. Erase the Burning Check Speed about 2-3 mbit per minute. Very suitable for amateur burning 24 and 25 series of FLASH. Support All versions of Microsoft Windows 7, 8, 10 etc & Linux & Mac OS Uses the USB port power supply For SPI & IIC Chip Programming (24 & 25 Series) Put the Programmer in Computer USB port Open the “CH341A programmer software” the burning software. Choose Chip Capacity if using 24 Series, Click Detect for auto Detection of Chip of 25 Series Can Burn Write, Erase & Backup Chips For Serial TTL Programming Set the Jumper Put the Programmer computer USB port, Programmer has Serial Pinouts of RX, TX & GND Connect RX Pin to TX Pin & TX pin to RX Pin & GND to GND Choose corresponding COM port, Open the Corresponding Download Software Platform for example (PUTTY for Serial Terminal Emulator)
