CD4027 – Dual JK FlipFlop
CD4027 – Dual JK FlipFlop, When we want to use flip-flops with CMOS. Often we meet CD4027. It is dual J-K flip-flops that are monolithic complementary MOS integrated circuits.
We have seen many circuits that use them. Of course, making a great circuit we should understand detail of any parts( basic enough).
Slow down!
If you are beginner. You should read how flip-flop works below.
Pin Configuration Description
This CD4027 IC has a total of 16 pins. As it is a dual flip flop IC, so it has 2 flip flops. All the pins, their name, and description are mentioned in the table given below.
Pin Number Pin Name Description
1, 15 Q2, Q1 Output pins
2, 14 , Inverted Output pins
3, 13 CLOCK 2, CLOCK 1 Clock pulse
4, 12 RESET 2, RESET 1 When this pin is LOW, the value of Q will be 1.
When this pin is HIGH, the value of inverted output () will be 1.
5, 11 K2, K1 Input Pin 1
6, 10 J2, J1 Input pin 2
7, 9 SET 2, SET 1 When this pin is HIGH, the value of Q will be 1.
When this pin is LOW, the value of inverted output () will be high.
8 Negative power Supply
16 Positive power supply
