General Purpose Signal Schottky Diode
40 V, 300 mA
Technical
The BAT54S from Diodes Inc is surface mount fast switching planar schottky barrier diode in SOT-23 package. These diode is single configured featured with PN junction guard ring for transient and ESD protection.
Peak repetitive reverse voltage of 30V
Non repetitive peak forward surge current is 600mA
Power dissipation is 200mW
Operating temperature range from -65°C to 150°C
Forward voltage of 800mV at IF 100mA
Reverse recovery time of 5ns
