43N60ND FET PRICE IN Pakistan

Type Designator: STW43NM60ND
Marking Code: 43NM60ND
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Pd ⓘ – Maximum Power Dissipation: 255 W
|Vds|ⓘ – Maximum Drain-Source Voltage: 600 V
|Vgs|ⓘ – Maximum Gate-Source Voltage: 25 V
|Vgs(th)|ⓘ – Maximum Gate-Threshold Voltage: 5 V
|Id| ⓘ – Maximum Drain Current: 35 A
Tj ⓘ – Maximum Junction Temperature: 150 °C
Qg ⓘ – Total Gate Charge: 145 nC
tr ⓘ – Rise Time: 40 nS
Cossⓘ – Output Capacitance: 250 pF
Rds ⓘ – Maximum Drain-Source On-State Resistance: 0.088 Ohm
Package: TO247
