Note: Not recommended to be compatible with low strings, The indicator light will flash and report an error. Before connecting the equalization board, be sure to check whether each battery is wired correctly, and do a good job of insulation. otherwise it will short-circuit and burn the board. If Buyer short-circuits and burns the board, Buyer needs to bear the responsibility instead of returning it. Thank you for acting with conscience.
Tips: The equalization board is not a BMS protection board, it is an auxiliary to the protection board, so no matter how bad the battery you use to test, it can be used, But it has no overvoltage/overdischarge protection function. Overvoltage/overdischarge is the function of the BMS protection board. If voltage protection is required, it is best to use it in parallel with the BMS protection board.
Applicable battery type: NCM(Li-ion)/LFP, NOT support LTO; Single voltage working range: 3.0V-4.2V; Suggested battery capacity: below 30AH, If more than 30AH, pls search Capacitor Faster Whole Group Balancer ” B096NLHXPF ” to purchase.
Balance method: Detect that the voltage difference between adjacent batteries is greater than 0.1V to trigger the start of equalization, and the adjacent battery voltage difference is less than 0.03V to stop working. (Tips: The inductance equalization board needs to be charged/discharged many times before the voltage equalization can achieve a better effect.)
Voltage balance accuracy: 30mV (typical value) between adjacent voltages; Balance current: 0.1V voltage difference 0.5A balance current, the maximum balance current is 1.2A when the voltage difference is above 0.2V. Static working current: 0.01mA; Under-voltage protection dormant voltage: The adjacent voltage difference is less than 0.03V and enters dormant state.
-10%
12V 3A 2 wire Touch Sensor Switch for Mirror Light (33x33x7)
