16X4 Character LCD 1604 Green LCD Display Module||Robostan
16X4 Character LCD 1604 Green LCD Display Module||Robostan. A LCD (Blue/Green) 16×4 character LCD display with white text on a vivid blue back-lit LCD. The pictures don’t do justice to the bright blue background with clear white text of this display. 4 lines of 16 characters. Standard Hitachi HD 44780 compatible interface for easy connection to micro-controllers. By liking Our Facebook Page Embeded Studio , you can get special discount. Datasheet for the LCD green/blue 16 x 4 can be download from the link.
Dimensions
Width 3.45 inches (87mm)
Height 2.35 inches (60mm)
Display view size 62mm x 26mm
FEATURES
Type: Character
Display format: 16 x 4 characters
Built-in controller: ST 7066 (or equivalent)
Duty cycle: 1/16 • 5 x 8 dots includes cursor
+ 5 V power supply (also available for + 3 V)
B/L to be driven by pin 1, pin 2, pin 15, pin 16 or A and K
N.V. optional for + 3 V power supply
LCD (Blue/Green) 16×4
Precautions in use of LCD Modules
(1)Avoid applying excessive shocks to the module or making any alterations or modifications to it.
(2)Don’t make extra holes on the printed circuit board, modify its shape or change the components of LCD module.
(3)Don’t disassemble the LCM.
(4)Don’t operate it above the absolute maximum rating.
(5)Don’t drop, bend or twist LCM.
(6)Soldering: only to the I/O terminals.
(7)Storage: please storage in anti-static electricity container and clean environment.
(8) Supplier had the right to change the passive components, including R3,R6 & backlight adjust resistors. (Resistors, capacitors and other passive components will have different appearance and color caused by the different supplier.)
(9)Supplier has the right to change the PCB Rev. (In order to satisfy the supplying stability, management optimization and the best product performance…etc, under the premise of not affecting the electrical characteristics and external dimensions, Vishay has the right to modify the version.)
