Relay/RelayModule

Features of 1 Channel 5 Volts Arduino Relay Module: With isolation groove in the control area and load area. With power and relay action indication, bright when connect and go off when disconnects. When there is a signal in signal input, public side and the common side will break over. It can be not only used as a microcontroller development board module but also as a home appliance control. It can not only control the DC or AC signal but the 220V AC load. With a permanent open and close vents contact. It is convenient to connect with blue KF301 terminal access control cable. Specification of Single One Channel 5V Best Arduino Relay Module: VCC: Power interface,5V GND: Ground IN: Control interface. Drive Current: At least 4mA COM: Control circuit ground, connect to GND Size: approx. 41 x 16 x 16mm/ 1.61 x 0.62 x 0.62'' Weight: Approx. 12g Package Includes: 1 x 1 Channel 5V Arduino Relay Module Best Online Shopping website for 1 Channel 5V Arduino Relay Module Single One Channel 5 Volts Relay Module For Arduino in cheap price in Karachi, Lahore, Islamabad, Rawalpindi, Sukkur, Peshawar, Multan, Quetta, Faisalabad and all over Pakistan.

Description Additional information Reviews (0) Description This 5V 1 Channel SSR G3MB-202P Solid State Relay Module 240V 2A Output with Resistive Fuse is based on the Omron G3MB SSR relay which can control up to 2A at 240VAC. .This is a 1 Channel SSR Solid State Relay module which has 3 separate terminals, NO (Normal Open), COM (Common), NC (Normal Closed) A Solid State Relay is similar to a mechanic relay where it can be controlled through a digital signal. Solid State Relay generates no noise and has a much longer lifespan in compared to the traditional mechanic relay. When the input logic voltage is applly to the coil, the NC will disconnect from the COM breaking the conductivity between the two. At the same time, the NO will connect with the COM allowing conductivity between them. Depending on your wiring this will turn on or off the connected load. Input parts : DC+: connect power positive DC-: connect power negative CH1: relay module signal trigger point (Effective low-level trigger) Features : Has been assembl, and the electrical test pass. It can be control directly by Microcontroller Input control signal voltage: 0-2.5V status low level, relay OFF 3-5V status high level, relay ON

Specifications Of 16 Channel Relay Board: Operating Voltage Range: 5-12V Maximum Voltage(V) : 250V AC Maximum Current(A) : 10 Supply Current (A) : 10mA Operating Temperature (°C) : -40 to 85 Opt. Relative Humidity(RH) : 20% ～ 85% Module Interface: 1. DC+: DC power supply positive pole 2. DC-: DC power supply negative pole 3. CH1~CH16: relay signal triggering pin Relay Output: 1. Normally closed pin (NC1~NC16): relay normally closed pin 2. Common pin (COM1~COM16): relay common pin 3. Normally opened pin (NO1~NO16): relay normally opened pin Package Includes: 1x Opto-isolated 16 Channel 5V Relay Module (Tested and QC-OK) Related Products: 5V 8 Channel Relay Module Board for Arduino 5V 1 CHANNEL RELAY MODULE FOR ARDUINO 6-30V 1 Channel Relay Module Switch Trigger Time Delay Circuit Timer Cycle Adjustable How to control 16 Channel Relay module using Arduino control:

The 5V 30A Relay Module is a versatile and essential component for controlling high-current devices in industrial applications. This powerful relay offers reliable switching, optocoupler isolation, and a wide range of features, making it ideal for various projects. Key Features: High Current Capacity: Handles loads up to 30A. 5V DC Control: Easily controlled by microcontrollers. Optocoupler Isolation: Provides electrical isolation for safety. Durable Construction: Built to last for long-term use. Versatile Applications: Suitable for industrial control, automation, and more. Specifications: Model Number: SLA-05VDC-SL-C Contact Load: High Power Theory: Electromagnetic Relay Power Source: DC 5V Current: 30A Pins: 6 Usage: General Purpose Order Now: Upgrade your industrial projects with our 5V 30A Relay Module. Experience the power, reliability, and versatility of this essential component.
